CBSE Class 6 Science Electricity And Circuit MCQs Set A

CBSE Class 6 Science Electricity And Circuit MCQs Set A with answers available in Pdf for free download. The MCQ Questions for Class 6 Science with answers have been prepared as per the latest 2021 syllabus, NCERT books and examination pattern suggested in Standard 6 by CBSE, NCERT and KVS. Multiple Choice Questions for important part of exams for Grade 6 Science and if practiced properly can help you to get higher marks. Refer to more Chapter wise MCQs for NCERT Class 6 Science and also download more latest study material for all subjects

5. ELECTRICITY AND CIRCUIT

Choose the correct answer from the bracket.

1. In electric bells electric energy transform in to ____________energy.

(a) Mechanical energy (b) Magnetic energy (c) Sound energy (d) Light energy

2.----------- is the positive terminal of an electric cell.

(a) Metal disc (b) Metal case (c) Metal cap (d) Metal base

3.The tiny coiled metal wire present inside the bulb is called____________.

(a) Element (b) Conductor (c) Filament (d) None of these

4. A combination of two or more electric cells is called___________.

(a) Electric circuit (b) Battery (c) Terminals (d) None of these

5. An electric bulb has ____________terminals.

(a) 3 (b) 4 (c) 1 (d) 2

6 ----------- is an electric device which easily closes or opens an electric circuit.

(a) Filament (b) Electric bulb (c) Electric switch (d) Electric cell

7. A material which does not allow the electricity to pass through it is___________.

(a) Conductor (b) Electric cell (c) Insulator (d) None of these.

8. Non metals like __________and __________are conductors of electricity.

(a)Wood and paper (b) Graphite and gas carbon (c) Glass and rubber (d) None of theses

9. A material which allows the electricity to pass through it is ________.

(a) conductor (b) Insulator (c) Transistor (d) None of these

10. Electric energy is produced from the____________ within the cell.

(a) Chemicals (b) Metals (c) Terminals (d) None of these

11. A complete electric circuit is called______________ electric circuit.

(a) open (b) Closed (c) Complete (d) None of these

12. ----------- is an insulator.

(a) Metal (b) acid (c) Rubber (d) Salt solution

13.__________is a conductor.

(a) Wood (b) Metal (c) Paper (d) Petrol

14. The electric current in a closed circuit always flows from the ___________terminal of the electric cell to the ______terminal.

(a) Negative to positive (b) Positive to negative (c) Positive to positive (d) None of these

15. The base of an electric cell is its ___________terminal.

(a) Positive terminal (b) Negative terminal (c) Negative and positive (d) None of these

16. The path along which electric current flows is_____________.

(a) Switch (b) Electric current (c) Electric circuit (d) Electric cell

17. In _____________ electrical energy is transformed in to mechanical energy.

(a) Transistor (b) Mixer grinder (c) Electromagnet (d) Electric bell.

18 ------------- is an energy which flows in an electric circuit.

(a)Electric circuit (b) Electromagnet (c) Electric current (d) None of these.

19. The central _____________of an electric cell is always positive.

(a) Circuit (b) Chemical (c) Terminal (d) None of these

20. Kerosene oil is an example of_______________.

(a) Conductors (b) Insulators (c) Electrolyte (d) None of these

21. The cylindrical container of electric cell is made of ___________ _and acts as negative terminal.

(a) Copper (b) Iron (c) Zinc (d) Silver

22. The wire which carries away the current to the power house is called____________.

(a) Earth wire (b) Neutral wire (c) Live wire (d) None of these

23._____________ is a safety wire which protect us from electric shocks and electric fire.

(a) Earth wire (b) Neutral wire (c) Live wire (d) None of these

24.____________ is a device which converts chemical energy in to electrical energy.

(a) Electrical bell (b) Electric lift (c) Electric cell (d) Electric bulb

25. An electric cell has ____________terminals.

(a) 3 (b)4 (c)1 (d)2



ANSWER KEY FOR ELECTRICITY & CIRCUITS



1)B 2)C 3)C 4)B 5)D 6)C 7)C 8)B 9)A 10)A 11)B 12)C 13)B 14)B 15)B 16)C 17)B 18)C 19)C 20)B 21)C 22)B 23)A 24)C 25)D
