CBSE Class 11 Physics Gravitation Notes Set 03

Class XI: Physics

Chapter 8: Gravitation

Chapter Notes

Key Learnings:

1. Newton’s law of universal gravitation states that the gravitational force of attraction between any two particles of masses m₁ and m₂ separated by a distance r has the magnitude F=G m₁m₂/r₂ Where G, the universal gravitational constant, has the value 6.672 x 10^-11 Nm² kg-².

2. From the principle of superposition each force acts independently and uninfluenced by the other bodies. The resultant force FR is then found by vector addition.

3. For small heights h above the earth’s surface the value of g decreases by a factor (1-2h/R).

4. The gravitational potential energy of two masses separated by a distance r is inversely proportional to r.

5. The potential energy is never positive; it is zero only when the two bodies are infinitely far apart.

6. The gravitational potential energy associated with two particles separated by a distance r is given by
V=-GM₁M₂/r  Where V is taken to be zero at r→ ∞.

7. The total mechanical energy is the sum of the kinetic and potential energies. The total energy is a constant of motion.

8. If an isolated system consists of a particle of mass m mobbing with a speed v in the vicinity of a massive body of mass M, the total mechanical energy of the particle is given by E=1/2mv²-GMm/r.

If m moves in circular orbit of radius a about M, where M >> m, the total energy of the system is E=-GMm/2a.

9. The escape speed from the surface of the Earth isve=√2GM_E/R_{E =}√2gR_E And has a value of 11.2 km s^-1.

10. Kepler’s law of planetary motion:

i. The orbit of the planet is elliptical with sun at one of the focus - LAW OF ORBITS.

ii. The line joining the planet to the sun sweeps out equal area in equal interval of time - LAW OF AREAS.

iii. The square of the planet’s time period of revolution T, is proportional to the cube of semi major axis a.

Please click the link below to download pdf file for CBSE Class 11 Physics - Gravitation Notes.
