Here is NEET Physics Electricity MCQs Set 03 for your practice. These MCQ Questions for NEET Electricity Physics come with answers and match updated NEET, NCERT, and KVS exam rules. Use additional chapter-wise MCQs for NEET NEET Physics to test your skills and find more study materials for all subjects.
Chapter MCQs: NEET Physics Electricity
Are you studying NEET Physics? Look at these 50 questions with answers to make your core concepts of Electricity very clear.
Electricity MCQ Questions NEET Physics with Answers
Question. Which of the following networks yields maximum effective resistance between A and B ?
Answer: A
Question. Which of the fol lowing network yields minimum current ?
Question. What is the total resistance between A and B in the given network (Fig.) ? Given the resistance of the galvanometer as 40Ω.
Question. Two charges are placed at a distance. If a glass slab is placed between them, force between them will be
(B) Increased
(D) Remains same
Answer: C
Question. The reciprocal of resistance is conductance.
If the unit of resistance is ohm, the unit of conductance will be -
(A) ohm
(B) volt
(C) mho
(D) ohm metre–1
Answer: C
Question. When the distance between the charged particles is halved, the force between them becomes -
(A) One-fourth
(B) Half
(C) Double
(D) Four times
Answer: D
Question. Two charges are placed at a distance apart.
If a glass slab is placed between them then force between them will -
(A) be zero
(B) increase
(C) decrease
(D) remain the same
Answer: C
Question. When the distance between two charged particles is halved, the force between them becomes:
(A) one-half
(B) double
(C) one-fourth
(D) four times.
Answer: C
Question. Charge on an electron is 1.6×10–19 coulomb. Number of electrons passing through the wire per second on flowing of 1 ampere current through the wire will be
(A) 0.625×10–19
(B) 1.6×10–19
(C) 1.6×10–19
(D) 0.625×1019
Answer: D
Question. Two wires of the same material having lengths in the ratio of 1 : 2 and diameters in the ratio 2 : 1 are connected with a cell of 6 volt and internal resistance 1Ω . The ratio of the potential difference across the two wires will be
(A) 1 : 2
(B) 2 : 1
(C) 1 : 8
(D) 8 : 1
Answer: C
Question. The value of current i in the given circuit is
(A) zero
(B) 5 amp.
(C) 7 amp.
(D) 11 amp.
Answer: D
Question. A wire of resistance 12 ohms is bent in the form of a circular ring. The effective resistance between the two points on any diameter of the circle is
(A) 24 ohm
(B) 12 ohm
(C) 6ohm
(D) 3 ohm
Answer: D
Question. In the circuit shown the ammeter A reads 4 amp. and the voltmeter V reads 20 volts. The value of the resistance R is
(A) slightly more than 5 ohms
(B) slightly less than 5 ohms
(C) Exact 5 ohms
(D) None of the above
Answer: A
Question. What is the potential difference across the source ?
(A) 440 V
(B) 220 V
(C) 120V
(D) 60V
Answer: C
Question. Two conduting wires of the same material and of equal lengths and equal diameters are first connected in series and then in parallel in a circuit across the same potential difference.
The ratio of heat produced in series and parallel combination would be :
(A) 1 : 2
(B) 2 : 1
(C) 1 : 4
(D) 4 : 1
Answer: C
Question. When current is passed through an electric bulb, its filament glows, but the wire leading current to the bulb does not glow because
(A) less current flows in the leading wire as compared to that in the filament
(B) the leading wire has more resistance than the filament
(C) the leading wire has less resistance then the filament
(D) filament has coating of fluorescent material over it
Answer: C
Question. When a fuse is rated 8 A, it means
(A) it will not work if current is less than 8 A
(B) it has a resistance of 8 ohm
(C) it will work only if current is 8 A
(D) it will burn if current exceeds 8 A
Answer: D
Question. What is the equivalent resistance between any two vertex of a triangle if the sides of the triangle are of equal resistance ?
(A) 3R
(B) 2R
(C) R
(D) 2R/3
Answer: D
Question. An electric bulb rated for 500 W at 100 V is used in a circult having a 200 V supply. The resistance 'R' that must be kept in series with the bulb so that the bulb draws 500 W is :
(A) 30Ω
(B) 5Ω
(C) 10Ω
(D) 20Ω
Answer: D
Question. A uniform wire of resistance 100W is melted and made in the form of uniform wire, whose length is double that of the original. The resistance of the new wire is:
(A) 200 √2 Ω
(B) 800 Ω
(C) 200 Ω
(D) 400 Ω
Answer: D
Question. Three 6 W resistors are connected in parallel and the combination is connected to a 15 V battery. The current through any one of the resistors will be :
(A) 2.5A
(B) 2.0A
(C) 5A
(D) 10A.
Answer: A
